Place of Origin:
China
Brand Name:
HelithTech
Model Number:
12.8V 200Ah LiFePO4 Battery
Contact Us
This 12.8V 200Ah lithium iron phosphate (LiFePO ₄) battery is designed specifically for high-performance energy storage applications, with excellent cycle life, safety, and stability. Adopting advanced BMS management system, supporting multiple series and parallel connections, suitable for scenarios such as home energy storage, communication base stations, RV RVs, solar energy systems, etc.
1, Ultra long cycle life: over 6000 cycles, far exceeding the lifespan of lead-acid batteries by 5-10 times
2, High safety performance: Good thermal stability, non flammable, non explosive, in compliance with UN38.3 and MSDS standards
3, Intelligent BMS management system: supports multi-dimensional protection and monitoring of voltage, current, temperature, etc
4, Flexible scalability: Supports multiple series and parallel connections, allowing for the free construction of 12V/24V/48V systems
5, Strong deep discharge performance: supports 100% DOD, improves actual available capacity
6, Green and environmentally friendly: no pollution, no heavy metals, compliant with RoHS standards
1, Household/Residential Solar Energy Storage System
2, RV/yacht backup power supply
3, Outdoor portable power system
4, Backup power supply for communication base stations
5, Industrial equipment/emergency power supply guarantee
6, UPS uninterruptible power supply system
Cell configuration: High quality A-grade LiFePO ₄ cells (3.2V 200Ah x 4 strings) are used
BMS system: Built in intelligent battery management system, with functions such as short circuit, overvoltage, undervoltage, overcurrent, temperature protection, etc
Charge and discharge compatibility: compatible with mainstream MPPT/inverter/charger brands (such as Victron, Growatt, Deye, etc.)
Customizable features: Bluetooth APP monitoring, CAN communication, LCD display, heating function, etc
| Cover Sealing Type | Screw / Gel Sealing Optional |
| LCD Screen Display | Optional (Show Voltage V, Power %) |
| Waterproof | IP65 |
| Model | Hertz 12200 |
| Max. Continuous Discharge Current | 100A |
| DC Resistance | ≤10mΩ |
| Dimension | 522x240x218mm |
| Terminal Type | Screw Terminal |
| Configuration | 4S2P |
| Nominal Capacity | 100AH |
The battery is configured with 4S2P, meaning that it has four cells connected in series and two parallel connections of these cells. This configuration allows for a high discharge rate and a longer lifespan compared to other batteries. The charging cut-off voltage is set at 14.6V, ensuring that the battery is not overcharged and prolonging its lifespan.
The 12.8V 200Ah LiFePO4 Battery is suitable for a wide range of product application occasions and scenarios. It is ideal for use in RVs, boats, and other vehicles where a reliable, long-lasting power source is required. It can also be used in solar energy systems, and can store energy from solar panels for later use. This battery is perfect for remote locations where access to traditional power sources is limited.
The battery's dimensions are 522x240x218mm, making it easy to install in a variety of applications. It is also lightweight compared to other batteries, making it easy to transport and install. Whether you need a 12V Nimh Battery replacement or a new energy storage lithium battery, the HelithTech 12.8V 200Ah LiFePO4 Battery is a reliable and cost-effective option.
Customize your 12V Lithium Ion Rechargeable Battery from HelithTech
Brand Name: HelithTech
Model Number: 12.8V 200Ah LiFePO4 Battery
Place of Origin: China
LCD Screen Display: Optional(Show Voltage V,Power %)
Operate Storage Temperature Range: -20°C~45°C
Model: Hertz 12200
Operate Charge Temperature Range: 0°C~55°C
Configuration: 4S2P
Choose the High Voltage LiFePO4 Battery that suits your needs and customize it to your preferences. The 12V Lithium Battery Pack is perfect for a variety of applications, including marine, RV, and solar power systems. With a durable and reliable design, the HelithTech battery is a great choice for anyone looking for a long-lasting and high-performance battery solution.
The 12V LiFePO4 Lithium Battery product comes with technical support and services to ensure optimal performance and longevity. Our team of experts is available to assist with any questions or issues you may encounter during installation, operation, or maintenance of the battery.
We offer comprehensive product documentation, including user manuals and technical specifications, to help you understand the capabilities and limitations of the battery. In addition, our team can provide guidance on proper charging and discharging procedures to ensure the battery operates at peak efficiency.
If you experience any issues with the battery, our technical support team is available to troubleshoot and diagnose the problem. We also offer repair and replacement services for defective or damaged batteries, subject to our warranty terms and conditions.
Overall, we are committed to providing the highest level of technical support and services to ensure your satisfaction with the 12V LiFePO4 Lithium Battery product.
Product Packaging:
Shipping:
Q: What is the brand of this battery?
A: The brand of this battery is HelithTech.
Q: What is the model number of this battery?
A: The model number of this battery is 12.8V 200Ah LiFePO4 Battery.
Q: Where is this battery made?
A: This battery is made in China.
Q: What is the capacity of this battery?
A: The capacity of this battery is 200Ah.
Q: What is the voltage of this battery?
A: The voltage of this battery is 12.8V.
