Place of Origin:
China
Brand Name:
HelithTech
Model Number:
Hertz 12100
Contact Us
Hertz 12100 is a 12V 100Ah lithium iron phosphate (LiFePO ₄) battery with high safety, long lifespan, and high energy efficiency, designed specifically for outdoor energy storage, RVs, ships, solar energy systems, and other applications. It adopts an advanced battery management system (BMS) to ensure safe charging and discharging, and supports parallel expansion to meet larger capacity requirements.
1, Ultra long lifespan - over 6000 cycles, more than 5 times longer than traditional lead-acid batteries.
2, High safety - using LiFePO ₄ battery cells, with excellent thermal stability and no risk of thermal runaway.
3, Lightweight design - only 11.5 kg, more than 60% lighter than lead-acid batteries of the same capacity, convenient to carry and install.
4, Efficient energy conversion - with a charging and discharging efficiency of up to 95%, reducing energy loss.
5,Intelligent BMS protection - equipped with overcharge, overdischarge, overcurrent, short circuit, and high temperature protection to ensure stable battery operation.
6, Parallel Expansion - Supports parallel connection of multiple batteries and flexible expansion of energy storage capacity.
1, RV&Camping - Portable energy storage that supports stable power supply for onboard appliances, refrigerators, lighting, and other devices.
2, Ships&yachts - lightweight design, corrosion-resistant, suitable for marine environments.
3, Solar energy storage system - combined with solar panels to achieve off grid energy storage and all-weather power supply.
4, UPS&Backup Power - To deal with sudden power outages and ensure the normal operation of critical equipment.
5, Outdoor homework&emergency rescue - providing reliable electricity, suitable for outdoor construction, disaster relief and other scenarios.
| Model | Hertz 12100 |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 100AH |
| Nominal Energy | 1280WH |
| Battery Cell Type | Prismatic 100Ah |
| Configuration | 4S1P |
| Max.Continous Charge Current | 100A |
| Max. Continous Discharge Current | 100A |
| DC Resistance | ≤10mΩ |
| Charging Cut-off Voltage | 14.6V |
| Discharging Cut-off Voltage | 10V |
| Operate Temperature Range | Charge: 0°C~55°C |
| Discharge: -20°C~60°C | |
| Storage: -20°C~45°C | |
| Dimension | 326x171x215mm |
| Weight | 12.5KG |
| Terminal Type | Screw terminal |
| Cover Sealing Type | Screw / gel sealing optional |
| Waterproof | IP65 |
| Cycle Life | >6000 Cycles (80%DOD) |
| LCD Screen Display | Optional(Show voltage V,Power %) |
| Bluetooth | Optional (Bluetooth with mobile APP) |
| Series & Parallels Function | Available to make in series and parallels to get 24V, 36V, 48V |
1. Can this battery be used for golf carts?
Yes, the Hertz 12100 is specifically designed for golf carts and other demanding applications, offering reliable performance and long cycle life.
2. Is the battery waterproof?
Yes, it has an IP65 waterproof rating, making it resistant to water and dust ingress.
3. Can the battery be connected in series or parallel?
Absolutely! It supports series and parallel connections to achieve configurations like 24V, 36V, or 48V.
4. What is the expected lifespan of the battery?
With over 6,000 cycles at 80% DOD, this battery offers many years of dependable service.
5. Does it come with a Bluetooth feature?
Bluetooth connectivity is optional and allows users to monitor the battery via a mobile app.
6. What is the charging cut-off voltage?
The charging cut-off voltage is 14.6V, ensuring safe and efficient charging.
7. Is there an LCD screen to check the battery status?
Yes, the LCD screen is an optional feature that displays the battery's voltage and power percentage.
