Product Introduction
The MagnaC-215 is a state-of-the-art AC outdoor liquid-cooled battery system developed by Helith Technology. Designed for utility-scale and commercial & industrial (C&I) energy storage applications, it combines high energy density, operational efficiency, and robust performance. With a rated energy capacity of 215 kWh and rated power of 100 kW, the MagnaC-215 delivers reliable energy solutions to support grid stability, peak shaving, and renewable energy integration. Its compact all-in-one design ensures easy installation and maintenance, while its liquid-cooling thermal management system provides exceptional temperature control for extended battery life.
| Parameter | Value |
| Model | Magna-C&I-215 |
| Product Category | AC Outdoor Liquid-cooling Battery System |
| Rated Energy | 215KWh@0.5C |
| Rated Power | 100W |
| Rated Output Voltage | 380 Va.c. |
| Cell Capacity | 280 Ah |
| Cell Type | LFP (Lithium Iron Phosphate) |
| Cell Configuration |
1P 240S |
| Max Discharge Current | 178 Ah |
| Max Charge Current | 178 Ah |
| Charge Temperature | 0~45°C |
| Discharge Temperature | -20~50°C |
| Communication Method | CAN, 485 |
| Thermal Management | Liquid-Cooled |
| Protection Level | IP55 |
| Weight | 2550 Kg |
| Dimensions | W1300 * D1310 * H2265 mm |
| Applications | Utility-scale, C&I |
Key Advantages
A-Grade LiFePO4 Cells
Built with premium-quality lithium iron phosphate (LFP) cells for superior safety, longevity, and performance.
Comprehensive BMS Protection
An advanced Battery Management System (BMS) safeguards the system with real-time monitoring and fault protection.
All-in-One Design
Integrates storage, cooling, and power electronics in a single compact unit for simplified installation.
High Operational Efficiency
Optimized for consistent and reliable performance, ensuring maximum return on investment.
Customizable Solutions
Flexible configurations to meet diverse energy storage requirements for different applications.
1. What is the primary application of the MagnaC-215?
The MagnaC-215 is ideal for utility-scale and commercial & industrial (C&I) energy storage projects, including peak shaving, renewable energy integration, and backup power.
2. How does the liquid-cooling system benefit the battery?
The liquid-cooling system ensures precise temperature control, improving performance, enhancing safety, and extending the lifespan of the battery under varying environmental conditions.
3. What makes LiFePO4 cells a superior choice?
LiFePO4 (LFP) cells offer high thermal stability, long cycle life, and excellent safety, making them an ideal choice for large-scale energy storage systems.
4. Can the system be customized for specific project needs?
Yes, Helith Technology provides tailored solutions to accommodate specific energy and power requirements for various applications.
5. What is the system's protection level?
The MagnaC-215 has an IP55 protection rating, ensuring reliable operation in outdoor environments.
